Polycyclic Aromatic Hydrocarbons (PAHs)

Polycyclic aromatic hydrocarbons (PAHs) are a group of over 100 different chemicals that are formed during the incomplete burning of coal, oil and gas, garbage, or other organic compounds. PAHs are known for their carcinogenic, mutagenic and teratogenic properties.

PAHs can be found in petrochemicals, rubber, plastics, lubricants, antirust oil, paints, leather and other products. Rubber and plastics are high risky materials containing PAHs. Tyre, electronics and toys are most affected by the restriction of PAHs in EU, German and US.

EU REACH Annex XVII has placed a restriction on the use of 8 PAHs in tyres and extender oil. Tyres will not be allowed to be placed on EU market if 8 PAHs exceed certain concentration thresholds listed in the following table. The restriction also applies to the marketing of tyres in EU.

Name

CAS

Structure

Limits

Benzo[a]pyrene

50-32-8

说明: 说明: C:\Users\Administrator\Desktop\50-32-8.gif

1 mg/kg

Benzo[e]pyrene

192-97-2

说明: 说明: C:\Users\Administrator\Desktop\192-97-2.gif

Sum of 8 PAHs < 10mg/kg

REACH has designated ISO 21461 as standard testing method for 8 PAHs in tyre.

For extender oil, IP346 is used.

According to the ISO 21461, tyres are compliant with the restriction on PAHs if the concentration of vulcanizates compound is not greater than 0.35% of Bay proton’s limit.

Benzo[a]anthracene

56-55-3

说明: 说明: C:\Users\Administrator\Desktop\56-55-3.gif

Chrysene

218-01-9

说明: 说明: C:\Users\Administrator\Desktop\218-01-9.gif

Benzo[b]fluoranthene

205-99-2

说明: 说明: C:\Users\Administrator\Desktop\205-99-2.gif

Benzo[k]fluoranthene

207-08-9

说明: 说明: C:\Users\Administrator\Desktop\207-08-9.gif

Benzo[j]fluorant

205-82-3

说明: 说明: C:\Users\Administrator\Desktop\205-82-3.gif

Dibenzo[a,h]anthrancene

53-70-3

说明: 说明: C:\Users\Administrator\Desktop\20603.gif



In addition to the EU restriction of 8 PAHs in tyre and extender oil, German has decided on the mandatory Polycyclic Aromatic Hydrocarbons (18 PAHs) testing for the GS-certification process. US EPA has restricted 16 PAHs in consumer goods.

The limits for PAHs that must be met for materials of consumer goods are stated in the following table:

Parameter

Category 1

Category 2

Category 3



Material in contact with foodstuff, or materials intended to be put in the
mouth and toys for children age of < 36 months

Materials with foreseeable contact to skin for longer
than 30 seconds (long-term skin contact) and toys not covered by category 1

Materials with
foreseeable contact to skin up to 30 seconds
(short term skin contact) or without skin contact

Benzo(a)pyrene mg/kg

Not detectable(< 0.2)

1

20

Sum 18 PAHs (EPA) mg/kg

Not detectable(< 0.2)

10

200

Our PAHs Testing Services

CIRS is the first and also the only third party testing agency in mainland China that offers PAHs testing services according to both ISO 21461 and the German ZEK method.

We offer PAHs testing services according to the following criteria:

  • EU REACH 8 PAHs;
  • German 18 PAHs;
  • US EPA 16 PAHs;
